STS9.5 Series for 1/1.7" C-Mount Telecentric Lens
With high telecentricity and low distortion, BASSON bi-telecentric lenses are mainly applied to precision measurement and high-precision visual positioning fields.
BASSON STS9.5 Series Standard Bi-telecentric Lenses are standard C-mount lenses, available for industrial cameras with maximum sensor size of 1/1.7” (diagonal of 9.5mm)
Features
lActual measured with full range of DOF, full range of FOV, and full range of wave length
lAvailable for Industrial Cameras with Sensor Size from 1/3” to 35Full
lLarge FOV from 11.5mm-315mm
lDistortion: <0.05% Telecentricity: <0.05°
lTG+ multi-layer coating, high transmittance
lOptions between high resolution and deep DOF are available
lCustomized aperture is available
lWorking distance can be adjusted within certain limits
lIndustrial grade waterproofing
